Product Description
This machine is designed for cutting any angle of aluminum curtain wall and window and door profile. The cutting angle is auto adjustable through the imported servo motor between 45˚ to 157.5˚
-The machine is the most advanced doubile-head cutting saw equipment for Aluminnum Window & Door.
-The control system adopts the new closed-loop sysstem.
-The servomotor drives the speed reducer to adjust angle in 45°～157.5°.
-Several profile processing dimensions can be input one time and make continuous cutting.
-The imported high precision blade makes the cutting surface more smooth.
-The processing dimension can be directly input, the cutting length can be changed without returning the reference point.
-The airproof device under the worktable has wonderful crumbs- clearing effect.
-The following saw cover keeps it working in the clean environment.
-The profile is clamped by two cylinders in every head, and kept the cutting security.
-The machine is the most advanced doubile-head cutting saw equipment for Aluminnum Window & Door.
-The control system adopts the new closed-loop sysstem.
-The servomotor drives the speed reducer to adjust angle in 45°～157.5°.
-Several profile processing dimensions can be input one time and make continuous cutting.
-The imported high precision blade makes the cutting surface more smooth.
-The processing dimension can be directly input, the cutting length can be changed without returning the reference point.
-The airproof device under the worktable has wonderful crumbs- clearing effect.
-The following saw cover keeps it working in the clean environment.
-The profile is clamped by two cylinders in every head, and kept the cutting security.
Product Parameters
| 技术参数 / Technical Parameters | |
| 电源 / Power supply | 3 Phase four wire 380V/50Hz |
| 锯头电机功率 / Cutting head motor power | 2x 2.2 kW |
| 旋转速度 / Rotate speed | 2800 r/min |
| 锯片摆角伺服电机功率/ Saw blade swing angle servo motor power | 0.9kW×2 |
| 机头水平移动伺服电机功率 / Cutting head horizontal move servo motor power | 1.5kW |
| 机头转角电机 / Cutting head turn angle motor power | 0.18kW x 2kW |
| 工作气压 / Woring air pressure | 0.5-0.8MPa |
| 锯切长度 / Saw cutting length | Max 5300mm |
| 锯切宽度X高度 / Saw cutting width x height | Max120 x 230 mm 90° |
| 锯切角度 / Saw cutting angle | blade 45° ~ 157.5° arbitrary angle |
| 进刀速度 无级调速/ Cutting feed speed stepless speed regulation | 0~ 3m/min |
| 锯片规格 / Blade specification | φ500 x 4.4 x φ30mm Z=120 |
| 外形尺寸 / Overall size | 7500 x 2450 x 1700mm |
| 重量 / Weight | about 2000kg |
