CNC Mosaic Glass Cutting Machine Automatic Small Glass Mosaic Tile Cutter

Basic Information

Place of Origin:	China
Brand Name:	GLAZONIC,GLAZONIC MACHINE
Model Series:

Payment & Shipping Terms

Minimum Order Quantity:	1 Set
Price:	Negotiable
Packaging Details:	Standard export packing
Delivery Time:	IN Stock
Payment Terms:	L/C, T/T, Western Union, MoneyGram, D/A, D/P
Supply Ability:	1 set,5 sets,10 sets,20 sets,50 sets,100 sets,

Inquire Now Whatsapp: 008617866711978

Product Description

Meta Description

CNC mosaic glass cutting machine, specially built for mass production of small mosaic glass tiles. High precision, can cut square, rectangle, irregular mosaic pieces, low chipping rate, ideal for mosaic factory and decorative glass workshop.

Product Introduction

The CNC Mosaic Glass Cutting Machine is a dedicated CNC glass cutting equipment developed for mass production of glass mosaic tiles. Different from standard large glass cutting tables, this machine is optimized for repeatedly cutting small-size glass pieces, solving the common pain points of manual mosaic processing: low output, inconsistent size, high chipping rate and heavy labor cost.
It adopts heavy-duty stress-relief welded steel frame and industrial CNC control system. With high-precision cutting head, it scores float glass, colored glass, mirror glass into small mosaic tiles, supports square, rectangle, rhombus and custom irregular mosaic patterns. Built-in intelligent nesting algorithm maximizes raw glass utilization and reduces waste. Equipped with air flotation table for scratch-free glass positioning. It is widely used in decorative mosaic factories, art glass workshops, wall tile and swimming pool mosaic production.

Core Functions

1. Optimized for Small Mosaic Tile Cutting
Specially tuned cutting pressure for small glass pieces. Minimum cutting size down to 10×10mm. Stable scoring for large batch of mosaic tiles, edge chipping rate greatly reduced compared with manual cutting.
2. CNC Intelligent Pattern Cutting
Support DXF drawing import. Freely program square, rectangular, diamond, curved and custom artistic mosaic shapes. Automatic nesting layout to save raw glass material. One-click batch repeated cutting for mass production.
3. Full Air Flotation Working Platform
Air cushion support, glass sheet can be moved and positioned smoothly without surface scratches. Perfect for colored decorative glass and mirror mosaic production.
4. High Precision Servo Drive System
X/Y axis full servo synchronous drive, stable and low vibration. Consistent dimensional accuracy for every small mosaic tile, avoiding size difference in finished mosaic sheets.
5. User-Friendly Control & Safety Protection
Industrial touch screen operation, simple programming. Emergency stop, overload protection and fault self-diagnosis. Operators can quickly master operation with short training.

Application Scenarios

Glass mosaic tile factory, art decorative glass workshop, swimming pool mosaic, wall & floor mosaic, stained glass project, mirror mosaic production.

Product Advantages

✅ Mass Mosaic Production: Optimized for small tile cutting, much higher output than manual cutting.
✅ Ultra Small Size Cutting: Minimum 10×10mm mosaic piece, meets fine mosaic artwork demand.
✅ Low Chipping & Stable Quality: Adjustable cutting pressure, uniform size, high finished yield.
✅ Material Saving Intelligent Nesting: Auto layout reduces glass scrap, lower raw material cost.
✅ Wide Material Compatibility: Works on float glass, colored glass, mirror, stained glass for mosaic.
✅ Compact Floor Space: Small footprint compared with large glass cutting machine, easy workshop layout.

Product Parameters

Item	Specification
Model	CNC Mosaic Glass Cutting Machine
Max Processing Size	1300mm × 1100mm
Min Mosaic Cutting Size	10mm × 10mm
Applicable Glass Thickness	2–8 mm
Cutting Precision	±0.1mm
Working Table Type	Air flotation table
Driving System	Full servo motor drive
Control System	CNC touch screen, support DXF import
Cutting Speed	0–120 m/min (adjustable)
Power Supply	380V / 50Hz
Total Power	6.5 KW
Overall Dimension	1800 × 1400 × 1200 mm
Machine Weight	2600 KG

Send Us Your Inquiry

GET A QUOTE

Tell us your requirements and our team will contact you with product details, pricing and shipping information.

Frequently Asked Questions

Q1: Are you a manufacturer?

A:Yes, we are a professional manufacturer with our own factory. You are welcome to visit us anytime.

Q2: Is your quotation based on the retail price for a single unit or the agent price?

A: Actually, the price is the same whether you buy just one unit or become an agent. But here’s the good part—if you’re an agent, we won’t sell in your designated territory at all. So even though the price is the same, you get full protection and exclusive opportunities in your market.

Q3: What are your payment terms?

A: We generally require staged payments: a 20% deposit upon order confirmation to secure production, and the remaining 80% balance should be settled before shipment.

Q4: Can I watch a real video of the machine before purchasing?

A: Absolutely! We provide demonstration videos, authentic customer feedback, and can arrange a live video call to show you the machine in actual operation.

Q5: What is your warranty policy?

A: Our warranty policy is as follows:
Basic Warranty:
A:One-year warranty for the whole machine.
B:Two-year warranty for core components (excluding consumables/spare parts).
After the warranty period: customers can purchase consumables and spare parts at distributor prices for life, and receive repair guidance via video or email.

Q6: Do I need to pay import taxes? How about the customs clearance process?

A: Import taxes depend on the regulations of your country/region. Normally, you need to pay local duties/taxes by yourself. However, we will prepare all necessary documents and assist you during the customs clearance process.

Q7: What is your production and delivery time?

A: For standard models, delivery usually takes 3–15 working days. For customized equipment, delivery usually takes 10–35 working days.

Q8: What kind of operation guidance do you provide after purchasing the machine?

A:English manuals and video tutorials.
B:One-on-one online training.
C:Option to dispatch professional engineers for on-site installation, commissioning, and training.

Q9: Can you deliver to my country? How much is the shipping cost?

A: Yes, we provide worldwide delivery service. Please provide your city and country/region, and we will recommend the best shipping method (by sea, air, or door-to-door) and offer you an accurate freight quotation.

Q10: Can I request customized equipment?

A: Of course. We can meet diverse customer needs. You can customize machine size, functions, materials, voltage, color, logo, and even the complete production line layout.
